HL-2000-CAL
The HL-2000-CAL Calibrated Tungsten Halogen Light Source can calibrate the absolute spectral response of a radiometric system. With this NIST-traceable light source and SpectraSuite, you can determine known absolute intensity values at wavelengths from 300-1050 nm. The HL-2000-CAL Calibrated Tungsten Halogen Light Source can be used to calibrate the absolute spectral response of a radiometric system. With this NIST-traceable light source and SpectraSuite Software.
Specifications
| Spectral range (calibrated): | 300-1050 nm (calibrated) |
| Power consumption: |
600 mA @ 12 VDC |
| Power output: | 6.5 watts |
| Bulb life: |
900 hours (recommend recalibration after 50 hours of use) |
| Recalibration: | Required after ~50 hours of operation |
| Bulb color temperature: |
3100 K |
| Output to bulb: | 5 volts/1.3 amps |
| Output regulation: | 0.2% voltage |
| Time to stabilized output: | ~30 minutes |
| Connector: | SMA 905 for fiber; 6.35-mm barrel for cosine corrector; PTFE plug for integrating sphere |
